Mobile Lösung zur Rauheitsmessung von Oberflächen
SURFCOM TOUCH Serie
![SURFCOM TOUCH: Portable surface roughness solution Portable surface roughness solution for any measurement challenge. Available with three tracing drivers for measurement on vertical surfaces.]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-product-image.ts-1535549071058.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=192%2C189%2C1536%2C1287&w=640&s=694352b871b2504b880da363986d2084","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-product-image.ts-1535549071058.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=192%2C189%2C1536%2C1287&w=1280&s=a5b157a171d4144605f59a4937cbd28f","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-product-image.ts-1535549071058.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=192%2C189%2C1536%2C1287&w=832&s=b374a952c2f9ef9b00e5cd7234caa6b2","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-product-image.ts-1535549071058.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=192%2C189%2C1536%2C1287&w=1920&s=5340cdaa3fd5f415a27a7d32cce7fbc5"})
Lösung zur Rauheitsmessung von Oberflächen für jede Messanforderung
Unsere intuitiv bedienbaren Oberflächenmessgeräte ermöglichen einfache Rauheitsmessungen an verschiedenen Arten von Werkstücken.
SURFCOM TOUCH Series
FunktionenAlle ZEISS SURFCOM TOUCH Systeme verfügen über einen intuitiven und einfach zu bedienenden Bildschirm zur
Kalibrierung, Messung und Analyse. Ein Verstärker mit einem 7-Zoll breiten Touchpanel und einer neuen Benutzeroberfläche sorgt für mehr Bedienkomfort. Die einfache Bedienung macht Anleitungen überflüssig.
Vorteile
- Es können Einstellungen der Sprache und des Symbol-Layouts vorgenommen sowie interne/USB-Speicher verwaltet werden.
- Weltweit verfügbare mehrsprachige Unterstützung
- Leicht verständliche Bedienungsanleitung/Kurzanleitung
- USB/Micro-USB-Anschlüsse gehören zur Standardausstattung
- Messergebnisse können schnell ausgedruckt werden
![Common functions of SURFCOM TOUCH All SURFCOM TOUCH systems come with an intuitive and easy-to-use screen for condition setting, calibration, measurement and analysis.]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-user-interface.ts-1535549076342.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=640&s=107d724c6a569da3ca5b913774faad83","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-user-interface.ts-1535549076342.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1280&s=d858b0bf40c92c51b30db43b1bf235c5","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-user-interface.ts-1535549076342.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=832&s=6afaca39a8d23141345d8d5304f99b81","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-user-interface.ts-1535549076342.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1920&s=0ac787745b443ba0d226867c0bf9810e"})
SURFCOM TOUCH 35/40/45
Tragbare Lösung zur Rauheitsmessung von Oberflächen für jede MessanforderungDas System ist mit drei kleinen und leicht geführten Tastantrieben für Messungen mit unterschiedlichen Einstellungen erhältlich. Neben horizontalen Flächen können auch Messungen an vertikalen Flächen in engen Bereichen mit einem quergeführten Tastantrieb durchgeführt werden.
![SURFCOM NEX 001: Outstanding roughness measuring station with a measuring speed of up to 20 mm/s. The SURFCOM NEX 001 surface measuring station enables highly effective roughness and waviness measurements.]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-standard.ts-1535634561594.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=214%2C251%2C436%2C327&w=640&s=1b3ccbc955eaf6d3dc315866cdfe2e93","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-standard.ts-1535634561594.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=214%2C251%2C436%2C327&w=1280&s=9ebd5594d41390bd527fac5066fd708a","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-standard.ts-1535634561594.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=214%2C251%2C436%2C327&w=832&s=85ad0c4aa10224798f30ae94dea01c02","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-standard.ts-1535634561594.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=214%2C251%2C436%2C327&w=1920&s=84ecca40dd3cd25ae404bafb80e1778a"})
SURFCOM TOUCH 35
Standard typ
Der Standardtyp mit verschiedenen Einstellungen zur Messung von horizontalen, geneigten, vertikalen und Deckenflächen.
![SURFCOM NEX 030: Efficient contour measurements with collision protection as a standard feature The SURFCOM NEX 030 is a flexible CNC contour measuring station and provides outstanding straightness accuracy in the X axis.]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-retraction-type.ts-1535627867953.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=4%2C0%2C1890%2C1417&w=640&s=9ebd4d7ee585df70cbbc7e80ce6c991d","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-retraction-type.ts-1535627867953.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=4%2C0%2C1890%2C1417&w=1280&s=d0fd4a1ab3e1cf02f34792ad0235f030","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-retraction-type.ts-1535627867953.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=4%2C0%2C1890%2C1417&w=832&s=77d7700ed7deaa256f5e7ce6ea72fe72","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-retraction-type.ts-1535627867953.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=4%2C0%2C1890%2C1417&w=1920&s=0a1fa90bc6440975b3c4f1c278d88b90"})
SURFCOM TOUCH 40
Rückzugstyp
Rückzugstyp, der die Beschädigung des Tasters und des Aufnehmers durch Anheben des Aufnehmers beim Warten auf die Messung oder am Ende reduziert.
![SURFCOM NEX 040: High-precision contour measuring station SURFCOM NEX 040 CNC measuring station with increased accuracy and automated probing force configuration]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-tracing-type.ts-1535627865772.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=0%2C143%2C960%2C720&w=640&s=dd13bce21def246bf71840001eb86ccc","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-tracing-type.ts-1535627865772.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=0%2C143%2C960%2C720&w=1280&s=59efdbebc8c11b562fcf4614af8bbd15","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-tracing-type.ts-1535627865772.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=0%2C143%2C960%2C720&w=832&s=bcf2dc41593a2e4a4736b4cce8129174","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-tracing-type.ts-1535627865772.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&rect=0%2C143%2C960%2C720&w=1920&s=ec7f024e346089d1ac9a0ad2cd1010e8"})
SURFCOM TOUCH 45
Horizontaltastung
Der Typ mit Querantrieb, bei dem sich der Aufnehmer seitlich bewegt.
![SURFCOM NEX 001: Outstanding roughness measuring station with a measuring speed of up to 20 mm/s. The SURFCOM NEX 001 surface measuring station enables highly effective roughness and waviness measurements.]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-surface-measurement.ts-1535549074078.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=640&s=2158c239262e774bfcaa4bf00c722c89","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-surface-measurement.ts-1535549074078.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1280&s=360ba91d2c7cc123e21bad4ae036d2f7","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-surface-measurement.ts-1535549074078.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=832&s=abd3346906f73c0a240b2147f917c3aa","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-surface-measurement.ts-1535549074078.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1920&s=c01c45b06b053abc9d6300336fad92da"})
Vorteile der tragbaren Lösungen zur Oberflächenrauheitsmessung
- Handflächengroßer Tastantrieb wählbar für Werkstücke und Messbereiche
- Eine als Zubehör angebotene Kalibriertabelle erleichtert die Kalibrierarbeit
- Optionale Aufnehmer ermöglichen verschiedene Messarten
SURFCOM TOUCH 50
HorizontaltastungErweiterter Messbereich der Z-Achse
Der Hochleistungsaufnehmer mit einem erweiterten Messbereich von 800 bis 1.000 μm und einer Mindestauflösung der Z-Achse von 0,0001 μm ermöglicht eine weitreichende und hochauflösende Freitastmessung. Neben einer ebenen Oberfläche kann auch die Rauheit oder Welligkeit auf einer welligen Oberfläche, z. B. einer gestuften oder runden Oberfläche, mit einem Messgang ausgewertet werden.
Vollständige Flexibilität
Freitastmessung mit einem Hochleistungsaufnehmer mit hoher Auflösung und großem Messbereich. Verschiedene Arten von Werkstücken können durch Wechseln des Tasters für tiefe, lange oder kleine Löcher oder eine runde Oberfläche vermessen werden.
Vorteile von SURFCOM TOUCH 50
Geeignet für die Messung zylindrischer Werkstücke, ein Tastantrieb kann mit Hilfe eines optionalen Rollenfußes auf die Werkstücke aufgesetzt werden. SURFCOM TOUCH 50 kann mit einem handlichen Tastantrieb verbunden werden.
![SURFCOM TOUCH 50: Surface roughness and straightness in one compact machine With SURFCOM TOUCH 50 skidless measurements with a high-performance pickup and high resulution can be performed.]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-50-measurement.ts-1535549073464.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=640&s=889648f7b91732fe72d491e5591b8954","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-50-measurement.ts-1535549073464.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1280&s=3bf35cb44822725824252d0337a8ec55","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-50-measurement.ts-1535549073464.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=832&s=923ad130daf96ef49984c2e2d137cb5d","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-50-measurement.ts-1535549073464.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1920&s=a0f1949e2fd66b3b4dad41b257b8cc88"})
SURFCOM TOUCH 550
High-End-Lösung mit elektrischen Messarm, für hohe Genauigkeit und GrößenvariabilitätErweiterter Messbereich
Der Hochleistungsaufnehmer mit einem erweiterten Messbereich von 800 bis 1.000 μm und einer Mindestauflösung der Z-Achse von 0,0001 μm ermöglicht eine weitreichende und hochauflösende Freitastmessung. Der Messbereich muss nicht berücksichtigt werden. Neben einer ebenen Oberfläche kann auch die Rauheit oder Welligkeit auf einer welligen Oberfläche, z. B. einer gestuften oder runden Oberfläche, mit einem Messgang ausgewertet werden. Auch das Nivellieren und Nullstellen vor der Messung lässt sich mühelos durchführen.
![SURFCOM TOUCH 550: High-end solution with an electric column offering high accuracy and size variation The high performing pickup with an extended measurement range from 800 to 1,000 μm and a Z-axis minimum resolution of 0.0001 μm allows for wide-range and high resolution skidless measurement.]({"small":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-550-product-image.ts-1535549070011.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=640&s=f6a39c04ea424ae109719ac81ccd9704","large":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-550-product-image.ts-1535549070011.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1280&s=9506af90373eaa15e600ce065ad3b3d7","medium":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-550-product-image.ts-1535549070011.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=832&s=f752f02d513b2c6f1eb1aacf5c84ffbf","full":"https://images.zeiss.com/metrology/products/systems/surface-roughness-measurement/contour-measurement/surfcom-touch/surfcom-touch-550-product-image.ts-1535549070011.jpg?auto=compress%2Cformat&fm=png&ixlib=java-1.1.11&w=1920&s=7ecb33e4227106cab7d39f26b0a7e76e"})
Flexible Größe des Geräts
Freitastmessung mit einem Hochleistungsaufnehmer mit hoher Auflösung und großem Messbereich. Verschiedene Arten von Werkstücken können durch Wechseln des Tasters für tiefe, lange oder kleine Löcher oder eine runde Oberfläche vermessen werden.
Optionale Ausstattung
Ein optionaler kompakter Messstand zum Messen von hohen Werkstücken oder Messungen mit Vorrichtungen.
Technische Daten für ZEISS SURFCOM TOUCH
SURFCOM TOUCH 35/40/45
|
SURFCOM TOUCH 35 |
SURFCOM TOUCH 40 |
SURFCOM TOUCH 45 |
Z direction |
-210 to +160 μm |
-210 to +160 μm |
-210 to +160 μm |
Drive axis |
X direction 16 mm |
X direction 16 mm |
Y direction 4 mm |
Movement type |
Standard type |
Retraction type |
Horizontal tracing type |
Evaluation length |
0.2 to 16 mm |
0.2 to 16 mm |
0.2 to 4.0 mm |
Measurement speed |
0.5, 0.6, 0.75, 1.0 mm/s |
0.5, 0.6, 0.75, 1.0 mm/s |
0.6 mm/s |
SURFCOM TOUCH 50
|
SURFCOM TOUCH 50 |
Z direction |
±500 μm |
X direction |
50 mm |
Evaluation length |
0.1 to 50 mm |
Straightness accuracy |
0.3 μm/50 mm |
Detector vertical movement volume |
50 mm |
Measurement speed |
0.15, 0.3, 0.6, 1.5, 3 / 0.05, 0.1, 0.2, 0.5, 1 mm/s |
SURFCOM TOUCH 550
|
SURFCOM TOUCH 550 |
Z direction |
±500 μm |
X direction |
100 mm to 200 mm |
Drive distance |
100 mm to 200 mm |
Straightness accuracy |
(0.05 + 1.5L/1000) μm |
Measurement speed |
0.03, 0.06, 0.15, 0.3, 0.6, 1.5, 3, 6 / 0.05, 0.1, 0.2, 0.5, 1, 2, 5 mm/s |
L: measurement length (mm)
